Product Introduction
Concrete Pump Truck on Mercedes-Benz Chassis
Mounted on Mercedes-Benz Actros or Arocs 6×4/8×4 chassis. Pumping height 32–52 meters, output 90–150 m³/h. S-valve system handles coarse aggregate. Remote radio control standard, end hose swivels for precise placement.
Product Parameters
|
Parameter |
Value |
|
Chassis Brand |
Mercedes-Benz |
|
Chassis Model |
AROCS 3345 6×4 / ACTROS 3348 6×4 |
|
Engine |
Mercedes-Benz Turbo Diesel |
|
Engine Power |
330–350 kW (450–476 PS) |
|
Max Torque |
2100 N·m |
|
Transmission |
12/16-speed automatic |
|
Drum Capacity |
8–10 m³ |
|
Drum Speed |
0–14 r/min |
|
Pump Model |
SANY HBT60C-1813D / XCMG HBT80/140C |
|
Max Pumping Output |
60–80 m³/h |
|
Max Pumping Pressure |
10–14 MPa |
|
Max Pumping Height |
150–200 m |
|
Max Pumping Distance |
500–800 m |
|
Discharge Height |
~2500 mm |
|
Wheelbase |
3900 + 1350 mm |
|
Dimensions (L × W × H) |
12,000 × 2,500 × 3,800 mm |
|
Max Speed |
≥90 km/h |
|
Tire Size |
12R22.5 / 315/80R22.5 |
|
Water Tank Capacity |
300–500 L |
Product Details
Product Highlights
Product Features
- Mercedes-Benz Actros/Arocs 6×4 or 8×4 chassis
- Pumping height 32–52 m (up to 62 m optional)
- Output 90–150 m³/h, S-valve system
- Remote radio control and swiveling end hose
- OM470 or OM501 engine, Euro V/VI compliant
Technical Advantages
The Mercedes-Benz OM470 or OM501 engine runs at low RPM for high torque – less strain on the pump drive. Steel frame rails are pre-drilled and reinforced at the mounting points, so the pump assembly sits on factory-planned hardpoints, not after-drilled holes.
S-valve distribution system uses hardened steel wear plates. Field data shows 20–30% longer life compared to gate-valve designs. The remote control operates at 400 meters range with dual frequency – no signal drop near steel rebar.
Arocs chassis adds a larger radiator and auxiliary cooling loop for the hydraulic oil. Pumping in hot climates (45°C ambient) won't trigger overheating shutdowns.
Our Factory
Packing & Delivery
Truck shipped complete with boom folded. Pump lines capped, remote packed separately, hoses coiled and tied. Whole unit covered by tarpaulin. Delivery: 30–40 days after deposit. Ro-Ro or bulk carrier. Basic tools and papers inside cab.
Partial Customer Reviews
FAQ
1. What chassis options are available?
Mercedes-Benz Actros or Arocs, in 6×4 or 8×4 drive. Arocs is better for heavy off-road jobs.
2. What is the pumping height range?
From 32 meters up to 62 meters, depending on the boom configuration you choose.
3. How much concrete can it pump per hour?
90 to 150 m³/h in standard mode. Higher output models reach 180 m³/h.
4. What engine power does it have?
OM501 (V6) around 408 hp, or OM470 (L6) up to 456 hp. Both meet Euro V or VI emission standards.
5. What is included as standard?
Radio remote control (dual frequency), swiveling end hose, S-valve system with hardened wear plates, and a water tank for cleaning.
6. How long until delivery?
30–40 days after deposit. Shipped as one unit with boom folded, hoses wrapped, tarpaulin cover. Ro-Ro or bulk carrier.
